Protected 3500mAh 10A 18650 Button Top Battery (Panasonic/Sanyo NCR18650GA cell inside) - Wholesale Discount
The LiionWholesale Protected 3500mAh (NCR18650GA) is a PCB protected button top version of the Sanyo NCR18650GA. This is a 3500 mAh 10 A battery and is one of the best batteries we offer for high discharge flashlights or other devices that need a high capacity but medium discharge protected battery. Its main competitor is the protected LG MJ1 which is a great alternative.
Compatible with 3.7V
Some companies market batteries like this as 3.7V 3500mAh, this will replace any 3.7V lithium ion with no issue. 3.7V vs 3.6V is just a labeling difference and is not an actual voltage difference inside the battery.
All protected NCR18650GA are not the same - the Liion Wholesale version is the best protected 18650 on the market
These are manufactured with a very high quality PCB including a Japanese Ricoh protection IC with three FNK MOSFETs for 20A high current cutoff (most PCBs will not be able to handle this much current). This protection circuit protects the battery from mishandling, overcharge, or overdischarge while allowing the battery to do its job properly.
The cell is made by Panasonic in their Japanese or Chinese plant. Our company then adds the high quality PCB along with the button top in an ISO certified factory to all safety standards. A black wrap is put over the top to hold it together.
Please note that these batteries do have a UN38.3 test report available and are legal for shipping. Many protected batteries on the market actually do not have any test data and are likely illegal for shipping due to lack of UN38.3 test report. Many competitors don't realize that a separate test needs to be done on the battery assembly and that the cell test is not enough. All of our batteries include a UN38.3 report available upon request.
If you need further certifications beyond UN38.3, I would recommend using our IEC62133, CB Scheme, and UL2054 certified Protected MJ1 Battery instead.
Quick Specs:
- Max Continuous Discharging Current: 10A
- Typical Capacity: 3500 mAh (3350mAh minimum)
- Style: BUTTON top
- Approximate Dimensions (including button): 69.1mm length x 18.6 mm diameter
- Discharge cut-off voltage: 2.5V (approximate)
- Voltage: 3.6V
- Full Charge Voltage: 4.2V
- Charge Current: 1.675A standard
- Protection Cutoff Current: ~20A
- Protection IC: Ricoh
- MOSFETS: (Quantity 3)
- Origin: Cell made in China or Japan, button top manufactured in China, Protection IC made in Japan
- Cell Certifications: UN38.3 test report, IEC62133, CB Scheme, UL1642
- Battery Assembly Certifications: UN38.3 test report
